Features
- High transmission capacity enables space saving by reducing the number of belts required
(approximately one-third compared with conventional V-belts).
- Excellent performance in oil resistance, heat resistance, flame resistance, aging resistance, and weather resistance.
- Excellent dimensional stability achieved through the combination of constituent materials and manufacturing methods, which, together with matched sets, enables uniform power transmission.
Structure
1.rubber-impregnated fabric
2.Polyester core wire
3.Neoprene insulating rubber
4.Special side reinforcement cord
5.Neoprene compression rubber
Dimensions and Names
 |
width of a garment (mm) |
thickness (mm) |
angle (°) |
|
| SPZ | 9.7 | 8.0 | 40 | |
| SPA | 12.7 | 10.0 | 40 | |
| SPB | 16.3 | 13.0 | 40 | |
| SPC | 22.0 | 18.0 | 40 |
